Article number:
66724
Article GTIN:
42406709217
Shure MXWAPX4
Access Point Transceiver with 4 or 8 wireless audio channels for use with MXW neXt wireless transmitters.
Specifications Analog, Dante, and USB-C audio connections. Built-in IntelliMix DSP audio processing with: Automatic mixing Echo cancellation Noise reduction Automatic gain control EQ Automatic Frequency Management: Scans the spectrum Selects a clear channel Automatically changes channels if interference is expected Power to the unit (via PoE) and Dante digital networked audio are both supplied over a single Ethernet cable to simplify installation. Dual RJ45 connections enable three network operation modes: Switched Split Redundant The supplied mounting plate and paintable cover allow discreet placement on the ceiling or wall in boardrooms and conference rooms where low visibility is preferred. Two-way wireless transmission: Allows for remote control of audio Enables transmission of a secondary program audio to each transmitter Multiple units can be combined to support: Up to 40 compatible channels 80 channels in Europe and select countries (double in HD mode) Supports standards-based security protocols to manage access and protect data, including: 802.1x Secure boot/storage AES encryption for wired and wireless control and audio data Selectable RF output power: Optimizes spectrum usage Allows selection of the appropriate wireless output power for the desired operating range Diagnostic LEDs provide an easy visual reference for system activity, indicating: Power status Wireless connection Network audio status A CUI (Control User Interface) can be accessed on a PC connected to the same network, enabling access to: All device properties Optimization settings User-specific settings Read more
Specifications Analog, Dante, and USB-C audio connections. Built-in IntelliMix DSP audio processing with: Automatic mixing Echo cancellation Noise reduction Automatic gain control EQ Automatic Frequency Management: Scans the spectrum Selects a clear channel Automatically changes channels if interference is expected Power to the unit (via PoE) and Dante digital networked audio are both supplied over a single Ethernet cable to simplify installation. Dual RJ45 connections enable three network operation modes: Switched Split Redundant The supplied mounting plate and paintable cover allow discreet placement on the ceiling or wall in boardrooms and conference rooms where low visibility is preferred. Two-way wireless transmission: Allows for remote control of audio Enables transmission of a secondary program audio to each transmitter Multiple units can be combined to support: Up to 40 compatible channels 80 channels in Europe and select countries (double in HD mode) Supports standards-based security protocols to manage access and protect data, including: 802.1x Secure boot/storage AES encryption for wired and wireless control and audio data Selectable RF output power: Optimizes spectrum usage Allows selection of the appropriate wireless output power for the desired operating range Diagnostic LEDs provide an easy visual reference for system activity, indicating: Power status Wireless connection Network audio status A CUI (Control User Interface) can be accessed on a PC connected to the same network, enabling access to: All device properties Optimization settings User-specific settings Read more
Access Point Transceiver with 4 or 8 wireless audio channels for use with MXW neXt wireless transmitters.
Specifications Analog, Dante, and USB-C audio connections. Built-in IntelliMix DSP audio processing with: Automatic mixing Echo cancellation Noise reduction Automatic gain control EQ Automatic Frequency Management: Scans the spectrum Selects a clear channel Automatically changes channels if interference is expected Power to the unit (via PoE) and Dante digital networked audio are both supplied over a single Ethernet cable to simplify installation. Dual RJ45 connections enable three network operation modes: Switched Split Redundant The supplied mounting plate and paintable cover allow discreet placement on the ceiling or wall in boardrooms and conference rooms where low visibility is preferred. Two-way wireless transmission: Allows for remote control of audio Enables transmission of a secondary program audio to each transmitter Multiple units can be combined to support: Up to 40 compatible channels 80 channels in Europe and select countries (double in HD mode) Supports standards-based security protocols to manage access and protect data, including: 802.1x Secure boot/storage AES encryption for wired and wireless control and audio data Selectable RF output power: Optimizes spectrum usage Allows selection of the appropriate wireless output power for the desired operating range Diagnostic LEDs provide an easy visual reference for system activity, indicating: Power status Wireless connection Network audio status A CUI (Control User Interface) can be accessed on a PC connected to the same network, enabling access to: All device properties Optimization settings User-specific settings Read more
Specifications Analog, Dante, and USB-C audio connections. Built-in IntelliMix DSP audio processing with: Automatic mixing Echo cancellation Noise reduction Automatic gain control EQ Automatic Frequency Management: Scans the spectrum Selects a clear channel Automatically changes channels if interference is expected Power to the unit (via PoE) and Dante digital networked audio are both supplied over a single Ethernet cable to simplify installation. Dual RJ45 connections enable three network operation modes: Switched Split Redundant The supplied mounting plate and paintable cover allow discreet placement on the ceiling or wall in boardrooms and conference rooms where low visibility is preferred. Two-way wireless transmission: Allows for remote control of audio Enables transmission of a secondary program audio to each transmitter Multiple units can be combined to support: Up to 40 compatible channels 80 channels in Europe and select countries (double in HD mode) Supports standards-based security protocols to manage access and protect data, including: 802.1x Secure boot/storage AES encryption for wired and wireless control and audio data Selectable RF output power: Optimizes spectrum usage Allows selection of the appropriate wireless output power for the desired operating range Diagnostic LEDs provide an easy visual reference for system activity, indicating: Power status Wireless connection Network audio status A CUI (Control User Interface) can be accessed on a PC connected to the same network, enabling access to: All device properties Optimization settings User-specific settings Read more
Specifications
| Accessory | Access point |
| Brand | Shure |
| Product range | Microflex Wireless |
