Martin Audio LE100
The LE100 is an extremely compact, two-way passive monitor. It features a 12” (300mm) LF /1” (25mm) exit HF Coaxial Differential Dispersion driver to distribute sound evenly over the listening plane. The LF driver section has a 2.5” (65mm) voice coil and an efficient motor system with an aluminium demodulating ring to minimise distortion. The coaxial HF driver utilises a 1.75” (44mm) polyimide dome and features a low-compression phase-plug to reduce non-linearity associated with overly-high compression ratios.
The unique Coaxial Differential Dispersion technology employed in the LE100 produces a horizontal coverage pattern which varies from a wide 110° directly over the monitor, reducing to 60° further back. This tapering produces a near-rectangular coverage plane at head-height to maintain the sound level and balance independent of distance from the monitor.
The LE100 enclosure is constructed from durable plywood and is finished with a durable black textured paint. Ergonomic pocket handles assist handling and a strong, perforated steel grille with an acoustically transparent cloth backing provides driver protection. Moulded feet prevent movement onstage and protect the base of the monitor from scratches.
As well as use as a stage monitor, the LE100 offers a range of flexible deployment options. It can be inverted and used as a pole-mounted sidefill or sound reinforcement system without the need to rotate the drive unit, or combined with a Martin Audio subwoofer as a drumfill. A removable pole-mount bung maintains clean lines in stage monitor guise while a total of five NL4 connectors at the front, base and in each handle pocket satisfy a wide variety of user configurations.
Specifications Type Two-way passive, Coaxial Differential Dispersion stage monitor Frequency Response (5) 78Hz-20kHz ± 3dB, -10dB @ 58Hz Drivers LF: 12” (300mm)/2.5” (63.5mm) voice coil, long excursion, shared ferrite motor system with HF
HF: 1” (25mm) exit/1.7” (44mm) voice coil, polyimide dome compression driver Rated Power (2) 300W AES, 1200W peak Sensitivity (8) 97dB Maximum SPL (9) 129dB peak Nominal Impedance 8Ω Dispersion (-6dB) 110°-60° horizontal, 60° vertical Crossover 1.6kHz passive Enclosure Birch/poplar ply Finish Black textured paint Protective Grille Black perforated steel with scrim cloth backing Baffle Angle 27˚ Connectors 5 x NL4 type Pin Connections 1+/1- Fittings 2 x pocket handles
Protective rubber feet on base and sides
4 x M8 inserts
Pole-mount socket Dimensions (W) 490mm x (H) 302mm x (D) 472mm
(W) 19.3ins x (H) 11.9ins x (D) 18.6ins Dimensions incl. Feet (W) 496mm x (H) 305mm x (D) 472mm
(W) 19.5ins x (H) 12.0ins x (D) 18.6ins Weight 18kg (39.7lbs) Read more
The unique Coaxial Differential Dispersion technology employed in the LE100 produces a horizontal coverage pattern which varies from a wide 110° directly over the monitor, reducing to 60° further back. This tapering produces a near-rectangular coverage plane at head-height to maintain the sound level and balance independent of distance from the monitor.
The LE100 enclosure is constructed from durable plywood and is finished with a durable black textured paint. Ergonomic pocket handles assist handling and a strong, perforated steel grille with an acoustically transparent cloth backing provides driver protection. Moulded feet prevent movement onstage and protect the base of the monitor from scratches.
As well as use as a stage monitor, the LE100 offers a range of flexible deployment options. It can be inverted and used as a pole-mounted sidefill or sound reinforcement system without the need to rotate the drive unit, or combined with a Martin Audio subwoofer as a drumfill. A removable pole-mount bung maintains clean lines in stage monitor guise while a total of five NL4 connectors at the front, base and in each handle pocket satisfy a wide variety of user configurations.
Specifications Type Two-way passive, Coaxial Differential Dispersion stage monitor Frequency Response (5) 78Hz-20kHz ± 3dB, -10dB @ 58Hz Drivers LF: 12” (300mm)/2.5” (63.5mm) voice coil, long excursion, shared ferrite motor system with HF
HF: 1” (25mm) exit/1.7” (44mm) voice coil, polyimide dome compression driver Rated Power (2) 300W AES, 1200W peak Sensitivity (8) 97dB Maximum SPL (9) 129dB peak Nominal Impedance 8Ω Dispersion (-6dB) 110°-60° horizontal, 60° vertical Crossover 1.6kHz passive Enclosure Birch/poplar ply Finish Black textured paint Protective Grille Black perforated steel with scrim cloth backing Baffle Angle 27˚ Connectors 5 x NL4 type Pin Connections 1+/1- Fittings 2 x pocket handles
Protective rubber feet on base and sides
4 x M8 inserts
Pole-mount socket Dimensions (W) 490mm x (H) 302mm x (D) 472mm
(W) 19.3ins x (H) 11.9ins x (D) 18.6ins Dimensions incl. Feet (W) 496mm x (H) 305mm x (D) 472mm
(W) 19.5ins x (H) 12.0ins x (D) 18.6ins Weight 18kg (39.7lbs) Read more
The LE100 is an extremely compact, two-way passive monitor. It features a 12” (300mm) LF /1” (25mm) exit HF Coaxial Differential Dispersion driver to distribute sound evenly over the listening plane. The LF driver section has a 2.5” (65mm) voice coil and an efficient motor system with an aluminium demodulating ring to minimise distortion. The coaxial HF driver utilises a 1.75” (44mm) polyimide dome and features a low-compression phase-plug to reduce non-linearity associated with overly-high compression ratios.
The unique Coaxial Differential Dispersion technology employed in the LE100 produces a horizontal coverage pattern which varies from a wide 110° directly over the monitor, reducing to 60° further back. This tapering produces a near-rectangular coverage plane at head-height to maintain the sound level and balance independent of distance from the monitor.
The LE100 enclosure is constructed from durable plywood and is finished with a durable black textured paint. Ergonomic pocket handles assist handling and a strong, perforated steel grille with an acoustically transparent cloth backing provides driver protection. Moulded feet prevent movement onstage and protect the base of the monitor from scratches.
As well as use as a stage monitor, the LE100 offers a range of flexible deployment options. It can be inverted and used as a pole-mounted sidefill or sound reinforcement system without the need to rotate the drive unit, or combined with a Martin Audio subwoofer as a drumfill. A removable pole-mount bung maintains clean lines in stage monitor guise while a total of five NL4 connectors at the front, base and in each handle pocket satisfy a wide variety of user configurations.
Specifications Type Two-way passive, Coaxial Differential Dispersion stage monitor Frequency Response (5) 78Hz-20kHz ± 3dB, -10dB @ 58Hz Drivers LF: 12” (300mm)/2.5” (63.5mm) voice coil, long excursion, shared ferrite motor system with HF
HF: 1” (25mm) exit/1.7” (44mm) voice coil, polyimide dome compression driver Rated Power (2) 300W AES, 1200W peak Sensitivity (8) 97dB Maximum SPL (9) 129dB peak Nominal Impedance 8Ω Dispersion (-6dB) 110°-60° horizontal, 60° vertical Crossover 1.6kHz passive Enclosure Birch/poplar ply Finish Black textured paint Protective Grille Black perforated steel with scrim cloth backing Baffle Angle 27˚ Connectors 5 x NL4 type Pin Connections 1+/1- Fittings 2 x pocket handles
Protective rubber feet on base and sides
4 x M8 inserts
Pole-mount socket Dimensions (W) 490mm x (H) 302mm x (D) 472mm
(W) 19.3ins x (H) 11.9ins x (D) 18.6ins Dimensions incl. Feet (W) 496mm x (H) 305mm x (D) 472mm
(W) 19.5ins x (H) 12.0ins x (D) 18.6ins Weight 18kg (39.7lbs) Read more
The unique Coaxial Differential Dispersion technology employed in the LE100 produces a horizontal coverage pattern which varies from a wide 110° directly over the monitor, reducing to 60° further back. This tapering produces a near-rectangular coverage plane at head-height to maintain the sound level and balance independent of distance from the monitor.
The LE100 enclosure is constructed from durable plywood and is finished with a durable black textured paint. Ergonomic pocket handles assist handling and a strong, perforated steel grille with an acoustically transparent cloth backing provides driver protection. Moulded feet prevent movement onstage and protect the base of the monitor from scratches.
As well as use as a stage monitor, the LE100 offers a range of flexible deployment options. It can be inverted and used as a pole-mounted sidefill or sound reinforcement system without the need to rotate the drive unit, or combined with a Martin Audio subwoofer as a drumfill. A removable pole-mount bung maintains clean lines in stage monitor guise while a total of five NL4 connectors at the front, base and in each handle pocket satisfy a wide variety of user configurations.
Specifications Type Two-way passive, Coaxial Differential Dispersion stage monitor Frequency Response (5) 78Hz-20kHz ± 3dB, -10dB @ 58Hz Drivers LF: 12” (300mm)/2.5” (63.5mm) voice coil, long excursion, shared ferrite motor system with HF
HF: 1” (25mm) exit/1.7” (44mm) voice coil, polyimide dome compression driver Rated Power (2) 300W AES, 1200W peak Sensitivity (8) 97dB Maximum SPL (9) 129dB peak Nominal Impedance 8Ω Dispersion (-6dB) 110°-60° horizontal, 60° vertical Crossover 1.6kHz passive Enclosure Birch/poplar ply Finish Black textured paint Protective Grille Black perforated steel with scrim cloth backing Baffle Angle 27˚ Connectors 5 x NL4 type Pin Connections 1+/1- Fittings 2 x pocket handles
Protective rubber feet on base and sides
4 x M8 inserts
Pole-mount socket Dimensions (W) 490mm x (H) 302mm x (D) 472mm
(W) 19.3ins x (H) 11.9ins x (D) 18.6ins Dimensions incl. Feet (W) 496mm x (H) 305mm x (D) 472mm
(W) 19.5ins x (H) 12.0ins x (D) 18.6ins Weight 18kg (39.7lbs) Read more
Specifications
| Powered/non-powered | Non-powered |
| Application | Touring |
| Brand | Martin Audio |
