Martin Audio SXC118 (White)
The recommended iK42 amplifier optimises the DSP parameters for front and rear drivers to maximise the rear rejection — from 21dB at 43Hz to 28dB at 75Hz. This keeps low frequencies away from stages, turntables and walls as well as reducing reverberant energy in the room, greatly improving the system’s low frequency response accuracy and impact.
In front of the enclosure, the output from the two drivers is additive, giving an extra 2dB of output when compared with a conventional 1 x 18” subwoofer.
The enclosure is constructed from plywood and finished with a hard-wearing textured paint. It is equipped with four grab handles and foam-backed perforated steel grilles protect the front and rear drivers. It can be used individually, stacked or flown individually by means of threaded flying inserts.
The SXC118 is an ideal partner for WPM and WPS line arrays or our range of point source loudspeakers where low frequency pattern control is required. Interlocking skids prevent movement when stacked and a threaded plate in the top surface facilitates pole-mounting of up to 4 WPM enclosures or a singular point source enclosure. The product is supplied as standard without castors but they can be purchased as an accessory.
By adding the input board cover accessory, the subwoofer is fully weather resistant and suitable for permanent outdoor usage.
Features Compact, cardioid subwoofer Front facing 18” (460mm)/4” (100mm) voice coil driver Rear facing 14” (356mm)/3.5” (88mm) voice coil driver Cardioid dispersion pattern 28dB rear rejection at 75Hz High output capability Tour-grade plywood enclosure with flying inserts Applications Live sound reinforcement Fixed installations including live event venues and nightclubs Theatre sound Corporate AV events Acoustically-challenging rooms Outdoor restaurant, bar and hotel entertainment areas Concourses and Theme Parks Read moreThe recommended iK42 amplifier optimises the DSP parameters for front and rear drivers to maximise the rear rejection — from 21dB at 43Hz to 28dB at 75Hz. This keeps low frequencies away from stages, turntables and walls as well as reducing reverberant energy in the room, greatly improving the system’s low frequency response accuracy and impact.
In front of the enclosure, the output from the two drivers is additive, giving an extra 2dB of output when compared with a conventional 1 x 18” subwoofer.
The enclosure is constructed from plywood and finished with a hard-wearing textured paint. It is equipped with four grab handles and foam-backed perforated steel grilles protect the front and rear drivers. It can be used individually, stacked or flown individually by means of threaded flying inserts.
The SXC118 is an ideal partner for WPM and WPS line arrays or our range of point source loudspeakers where low frequency pattern control is required. Interlocking skids prevent movement when stacked and a threaded plate in the top surface facilitates pole-mounting of up to 4 WPM enclosures or a singular point source enclosure. The product is supplied as standard without castors but they can be purchased as an accessory.
By adding the input board cover accessory, the subwoofer is fully weather resistant and suitable for permanent outdoor usage.
Features Compact, cardioid subwoofer Front facing 18” (460mm)/4” (100mm) voice coil driver Rear facing 14” (356mm)/3.5” (88mm) voice coil driver Cardioid dispersion pattern 28dB rear rejection at 75Hz High output capability Tour-grade plywood enclosure with flying inserts Applications Live sound reinforcement Fixed installations including live event venues and nightclubs Theatre sound Corporate AV events Acoustically-challenging rooms Outdoor restaurant, bar and hotel entertainment areas Concourses and Theme Parks Read moreSpecifications
Driver Configuration | Single |
DSP | Yes |
Bluetooth Connectivity | No |
Connectivity | Analog |
Powered/non-powered | Non-powered |
Max. Frequency (Hz) | 150 |
Min. Frequency (Hz) | 43 |
Max. SPL (dB) | 140 |
WiFi Connectivity | No |
Enclosure | Wood |
Application | Install & Touring |
Weatherized | No |
Brand | Martin Audio |
