Martin Audio WPS (White)
WPS is a passive 3-way system which integrates a high density of drive units in a very compact enclosure. It features 2 x 8” (200mm) LF drivers, 4 x 4” (100mm) midrange drivers and 4 x 1” (25mm) exit HF compression drivers loaded by a moulded HF horn which occupies the full width of the enclosure — defining the 100° horizontal constant directivity coverage pattern of both the HF and midrange sections.
The 4” midrange drivers are compression-loaded to raise efficiency and enter the horn walls via annular slots close to the HF throat to sum effectively with the HF wavefront. In the HF section, four 1” exit compression drivers deliver pristine high frequency sound without the harshness and distortion associated with larger format devices.
The 8” LF drivers are set back behind the walls of the HF horn, with a small volume of air in front of each driver increasing the output at the upper end of its operating range. The LF exit apertures are spaced apart horizontally to provide useful LF horizontal pattern control.
For extended low frequency performance, WPS is designed to be partnered with the SXC118 cardioid subwoofer or its flyable variant, the SXCF118.
WPS is also available in a marine variant, built to order in black or white. This product is suitable for permanent outdoor installation and its corresponding datasheet can be found here:
Features 3-way passive, 2 x 8” small line array Scalable resolution for advanced array control External, dedicated, multi-channel Class D amplification Industry-leading DISPLAY software interacts with DSP for highly-accurate results Fast, integral 3-point flying systems for up to 16 enclosures Side and rear handles for ease of handling and setting splayangles 100° horizontal constant directivity pattern control Applications Touring sound reinforcement for small and medium-size venues Fixed installations in concert halls, theatres, ballrooms and HoW Sports stadium, arena installations & corporate AV events Read moreWPS is a passive 3-way system which integrates a high density of drive units in a very compact enclosure. It features 2 x 8” (200mm) LF drivers, 4 x 4” (100mm) midrange drivers and 4 x 1” (25mm) exit HF compression drivers loaded by a moulded HF horn which occupies the full width of the enclosure — defining the 100° horizontal constant directivity coverage pattern of both the HF and midrange sections.
The 4” midrange drivers are compression-loaded to raise efficiency and enter the horn walls via annular slots close to the HF throat to sum effectively with the HF wavefront. In the HF section, four 1” exit compression drivers deliver pristine high frequency sound without the harshness and distortion associated with larger format devices.
The 8” LF drivers are set back behind the walls of the HF horn, with a small volume of air in front of each driver increasing the output at the upper end of its operating range. The LF exit apertures are spaced apart horizontally to provide useful LF horizontal pattern control.
For extended low frequency performance, WPS is designed to be partnered with the SXC118 cardioid subwoofer or its flyable variant, the SXCF118.
WPS is also available in a marine variant, built to order in black or white. This product is suitable for permanent outdoor installation and its corresponding datasheet can be found here:
Features 3-way passive, 2 x 8” small line array Scalable resolution for advanced array control External, dedicated, multi-channel Class D amplification Industry-leading DISPLAY software interacts with DSP for highly-accurate results Fast, integral 3-point flying systems for up to 16 enclosures Side and rear handles for ease of handling and setting splayangles 100° horizontal constant directivity pattern control Applications Touring sound reinforcement for small and medium-size venues Fixed installations in concert halls, theatres, ballrooms and HoW Sports stadium, arena installations & corporate AV events Read moreSpecifications
Driver Configuration | 2-way |
DSP | Yes |
Bluetooth Connectivity | No |
Connectivity | Analog |
Powered/non-powered | Non-powered |
Min. Frequency (Hz) | 70 |
Max. SPL (dB) | 133 |
WiFi Connectivity | No |
Max. Frequency (kHz) | 18 |
Enclosure | Wood |
Application | Install |
Weatherized | No |
Brand | Martin Audio |
