Article number:
66742
Article GTIN:
5906660592167
Portman Omniray
THE WORLD’S FIRST HYBRID UTILITY FIXTURE!
OMNIRAY™ introduces a brand-new category of stage lighting: the Hybrid Utility Fixture.You can use it as a high-quality wash light, a narrow beam, a powerful blinder, or a decorative eye-candy.Its all-in-one design means you can achieve more with fewer fixtures, saving time, space, and costs.NO MORE boring, flat, single-purpose PARs, blinders, wash lights!
TWO LIGHT SOURCES
Narrow beam: 40 W RGBW 3.8°
Wide and powerful 440 W RGBW LA 85°> 95 CRI
KALEIDOSCOPE OF POSSIBILITIES
OMNIRAY™ takes versatility to the next level with its range of magnetic lens overlays and accessories. Designed for effortless attachment and precision, these accessories expand the creative potential of your lighting.
MAGNETIC BEAM SHAPERS
• Frost diffusers
• Elliptical diffusers
• Fresnel lenses
MAGNETIC COVERS
• Decoratives
• Barn doors
The overlays lock securely at a 45° angle and can be stacked.
PRECISE TILT & STABLE YOKE
Precision tilt system locks every 5°.
A large yoke plate with cam locks, allows quick setup and stability.
STAGE READY
IP65-rated powerful wash light with tungsten blinder emulation. Smooth dimming and additional mid-air effects.
TV/FILM/THEATRE PRODUCTION READY
12.5KHZ flicker-free performance, 16-bit dimming and color mixing, CRI >95, and silent fan mode.
SMARTPHONE-LIKE CONTROL
Large, responsive touch display for easy operation. Intuitive menu, USB-port for firmware updates via Flash drive.
Color feedback system indicating issues such as DMX-signal loss.
Specifications Weight (Fixture Only) 14 kg / 30.87 lbs Protection Rating IP65 Input Voltage 100-240 V 50/60 Hz Max Power Consumption 500 W Power Connectors AC power in/thru: powerCON TRUE1 Light Sources Main Source: 440 W RGBWLA
Narrow Source: 40 W RGBW Beam Angle 85° / 3.8° Colour Temperature 2000 – 6500 K / 6000 K CRI > 95 (calibrated mode) Control Connectors DMX/RDM data in/thru: 5-pin XLR
Firmware from flash drive: USB A Control Features 8 DMX modes (8-28 channels)
RDM
Macros
CRMX (optional module) User Interface OLED touch display
Highlighted buttons
Colour Feedback System™ – fixture’s auto information status Certificates CE, ROHS, ETL, UL, UKCA Intellectual Protection Design patent
Utility patent (pending)
Trademark Warranty 24 m What’s in the Box Fixture
AC power cord (PowerCon TRUE1/no AC plug)
User manual
OMNICLE™ – decorative magnetic cover Additional Accessories Rigging:
- Omega bracket with 1/4 fast locks
Optics – Magnetic:
- Diffuser (avg)
- Diffuser (strong)
- Elliptical diffuser (10×40)
- Elliptical diffuser (10×60)
- Fresnel lens
Control Features:
- CRMX
Packing:
- Flight case Read more
OMNIRAY™ introduces a brand-new category of stage lighting: the Hybrid Utility Fixture.You can use it as a high-quality wash light, a narrow beam, a powerful blinder, or a decorative eye-candy.Its all-in-one design means you can achieve more with fewer fixtures, saving time, space, and costs.NO MORE boring, flat, single-purpose PARs, blinders, wash lights!
TWO LIGHT SOURCES
Narrow beam: 40 W RGBW 3.8°
Wide and powerful 440 W RGBW LA 85°> 95 CRI
KALEIDOSCOPE OF POSSIBILITIES
OMNIRAY™ takes versatility to the next level with its range of magnetic lens overlays and accessories. Designed for effortless attachment and precision, these accessories expand the creative potential of your lighting.
MAGNETIC BEAM SHAPERS
• Frost diffusers
• Elliptical diffusers
• Fresnel lenses
MAGNETIC COVERS
• Decoratives
• Barn doors
The overlays lock securely at a 45° angle and can be stacked.
PRECISE TILT & STABLE YOKE
Precision tilt system locks every 5°.
A large yoke plate with cam locks, allows quick setup and stability.
STAGE READY
IP65-rated powerful wash light with tungsten blinder emulation. Smooth dimming and additional mid-air effects.
TV/FILM/THEATRE PRODUCTION READY
12.5KHZ flicker-free performance, 16-bit dimming and color mixing, CRI >95, and silent fan mode.
SMARTPHONE-LIKE CONTROL
Large, responsive touch display for easy operation. Intuitive menu, USB-port for firmware updates via Flash drive.
Color feedback system indicating issues such as DMX-signal loss.
Specifications Weight (Fixture Only) 14 kg / 30.87 lbs Protection Rating IP65 Input Voltage 100-240 V 50/60 Hz Max Power Consumption 500 W Power Connectors AC power in/thru: powerCON TRUE1 Light Sources Main Source: 440 W RGBWLA
Narrow Source: 40 W RGBW Beam Angle 85° / 3.8° Colour Temperature 2000 – 6500 K / 6000 K CRI > 95 (calibrated mode) Control Connectors DMX/RDM data in/thru: 5-pin XLR
Firmware from flash drive: USB A Control Features 8 DMX modes (8-28 channels)
RDM
Macros
CRMX (optional module) User Interface OLED touch display
Highlighted buttons
Colour Feedback System™ – fixture’s auto information status Certificates CE, ROHS, ETL, UL, UKCA Intellectual Protection Design patent
Utility patent (pending)
Trademark Warranty 24 m What’s in the Box Fixture
AC power cord (PowerCon TRUE1/no AC plug)
User manual
OMNICLE™ – decorative magnetic cover Additional Accessories Rigging:
- Omega bracket with 1/4 fast locks
Optics – Magnetic:
- Diffuser (avg)
- Diffuser (strong)
- Elliptical diffuser (10×40)
- Elliptical diffuser (10×60)
- Fresnel lens
Control Features:
- CRMX
Packing:
- Flight case Read more
THE WORLD’S FIRST HYBRID UTILITY FIXTURE!
OMNIRAY™ introduces a brand-new category of stage lighting: the Hybrid Utility Fixture.You can use it as a high-quality wash light, a narrow beam, a powerful blinder, or a decorative eye-candy.Its all-in-one design means you can achieve more with fewer fixtures, saving time, space, and costs.NO MORE boring, flat, single-purpose PARs, blinders, wash lights!
TWO LIGHT SOURCES
Narrow beam: 40 W RGBW 3.8°
Wide and powerful 440 W RGBW LA 85°> 95 CRI
KALEIDOSCOPE OF POSSIBILITIES
OMNIRAY™ takes versatility to the next level with its range of magnetic lens overlays and accessories. Designed for effortless attachment and precision, these accessories expand the creative potential of your lighting.
MAGNETIC BEAM SHAPERS
• Frost diffusers
• Elliptical diffusers
• Fresnel lenses
MAGNETIC COVERS
• Decoratives
• Barn doors
The overlays lock securely at a 45° angle and can be stacked.
PRECISE TILT & STABLE YOKE
Precision tilt system locks every 5°.
A large yoke plate with cam locks, allows quick setup and stability.
STAGE READY
IP65-rated powerful wash light with tungsten blinder emulation. Smooth dimming and additional mid-air effects.
TV/FILM/THEATRE PRODUCTION READY
12.5KHZ flicker-free performance, 16-bit dimming and color mixing, CRI >95, and silent fan mode.
SMARTPHONE-LIKE CONTROL
Large, responsive touch display for easy operation. Intuitive menu, USB-port for firmware updates via Flash drive.
Color feedback system indicating issues such as DMX-signal loss.
Specifications Weight (Fixture Only) 14 kg / 30.87 lbs Protection Rating IP65 Input Voltage 100-240 V 50/60 Hz Max Power Consumption 500 W Power Connectors AC power in/thru: powerCON TRUE1 Light Sources Main Source: 440 W RGBWLA
Narrow Source: 40 W RGBW Beam Angle 85° / 3.8° Colour Temperature 2000 – 6500 K / 6000 K CRI > 95 (calibrated mode) Control Connectors DMX/RDM data in/thru: 5-pin XLR
Firmware from flash drive: USB A Control Features 8 DMX modes (8-28 channels)
RDM
Macros
CRMX (optional module) User Interface OLED touch display
Highlighted buttons
Colour Feedback System™ – fixture’s auto information status Certificates CE, ROHS, ETL, UL, UKCA Intellectual Protection Design patent
Utility patent (pending)
Trademark Warranty 24 m What’s in the Box Fixture
AC power cord (PowerCon TRUE1/no AC plug)
User manual
OMNICLE™ – decorative magnetic cover Additional Accessories Rigging:
- Omega bracket with 1/4 fast locks
Optics – Magnetic:
- Diffuser (avg)
- Diffuser (strong)
- Elliptical diffuser (10×40)
- Elliptical diffuser (10×60)
- Fresnel lens
Control Features:
- CRMX
Packing:
- Flight case Read more
OMNIRAY™ introduces a brand-new category of stage lighting: the Hybrid Utility Fixture.You can use it as a high-quality wash light, a narrow beam, a powerful blinder, or a decorative eye-candy.Its all-in-one design means you can achieve more with fewer fixtures, saving time, space, and costs.NO MORE boring, flat, single-purpose PARs, blinders, wash lights!
TWO LIGHT SOURCES
Narrow beam: 40 W RGBW 3.8°
Wide and powerful 440 W RGBW LA 85°> 95 CRI
KALEIDOSCOPE OF POSSIBILITIES
OMNIRAY™ takes versatility to the next level with its range of magnetic lens overlays and accessories. Designed for effortless attachment and precision, these accessories expand the creative potential of your lighting.
MAGNETIC BEAM SHAPERS
• Frost diffusers
• Elliptical diffusers
• Fresnel lenses
MAGNETIC COVERS
• Decoratives
• Barn doors
The overlays lock securely at a 45° angle and can be stacked.
PRECISE TILT & STABLE YOKE
Precision tilt system locks every 5°.
A large yoke plate with cam locks, allows quick setup and stability.
STAGE READY
IP65-rated powerful wash light with tungsten blinder emulation. Smooth dimming and additional mid-air effects.
TV/FILM/THEATRE PRODUCTION READY
12.5KHZ flicker-free performance, 16-bit dimming and color mixing, CRI >95, and silent fan mode.
SMARTPHONE-LIKE CONTROL
Large, responsive touch display for easy operation. Intuitive menu, USB-port for firmware updates via Flash drive.
Color feedback system indicating issues such as DMX-signal loss.
Specifications Weight (Fixture Only) 14 kg / 30.87 lbs Protection Rating IP65 Input Voltage 100-240 V 50/60 Hz Max Power Consumption 500 W Power Connectors AC power in/thru: powerCON TRUE1 Light Sources Main Source: 440 W RGBWLA
Narrow Source: 40 W RGBW Beam Angle 85° / 3.8° Colour Temperature 2000 – 6500 K / 6000 K CRI > 95 (calibrated mode) Control Connectors DMX/RDM data in/thru: 5-pin XLR
Firmware from flash drive: USB A Control Features 8 DMX modes (8-28 channels)
RDM
Macros
CRMX (optional module) User Interface OLED touch display
Highlighted buttons
Colour Feedback System™ – fixture’s auto information status Certificates CE, ROHS, ETL, UL, UKCA Intellectual Protection Design patent
Utility patent (pending)
Trademark Warranty 24 m What’s in the Box Fixture
AC power cord (PowerCon TRUE1/no AC plug)
User manual
OMNICLE™ – decorative magnetic cover Additional Accessories Rigging:
- Omega bracket with 1/4 fast locks
Optics – Magnetic:
- Diffuser (avg)
- Diffuser (strong)
- Elliptical diffuser (10×40)
- Elliptical diffuser (10×60)
- Fresnel lens
Control Features:
- CRMX
Packing:
- Flight case Read more
Specifications
| Compatible with (optional) wireless DMX | Yes |
| Fixture type | Effect lights |
| Outdoor usage | No |
| Complimentary colors | LA |
| Lumens | Not specified |
| Application | Touring |
| Colors | RGBW |
| Source | LED |
| Brand | Portman |
