Article number:
64153
e:cue LCE 3 MX
Compact, reliable, flexible. The Lighting Control Engine mx (LCEmx) has no moving parts such as fans or hard disks and can be mounted on DIN rails, on walls or in racks. Nevertheless, it has all the connections, functions and performance expected for demanding lighting projects. Equipped with high-quality components and developed for industrial use, it is the perfect server for small to medium-sized lighting installations.Engines for DMX output such as Butler or Butler XT are connected via e:net, and other network protocols such as KiNet or Art-Net are also supported. Special features such as an externally accessible CompactFlash card slot, operation without a monitor and keyboard, the SATA2 solid state drive or the wide range of mounting options make the LCEmx an exceptional system as the heart of a lighting control solution.
At a Glance
Pre-installed e:cue Lighting Application Suite with internal enterprise dongle High-quality components for reliable operation Certified for industrial use Fanless operation, no moving parts thanks to SSD drive Up to 8 GB CompactFlash card in card slot USB, RS-232 and DVI interfaces 2 x e:net/Ethernet (RJ45) Supports a wide range of Ethernet-based protocols Easy to mount on DIN rail or on walls Headless operation without keyboard and monitor Supplied without keyboard, mouse and monitor Technical Data
Dimensions (W x H x D): 262 x 134 x 47 mm Housing Dimensions incl. top-hat rail terminals: 262 x 134 x 50 mm incl. top-hat rail terminals Weight: 2 kg Power supply: external 24 V=; 19.2 ... 28.8 V= electrically isolated Protection class: IP20 Video output: DVI-DRead more
At a Glance
Pre-installed e:cue Lighting Application Suite with internal enterprise dongle High-quality components for reliable operation Certified for industrial use Fanless operation, no moving parts thanks to SSD drive Up to 8 GB CompactFlash card in card slot USB, RS-232 and DVI interfaces 2 x e:net/Ethernet (RJ45) Supports a wide range of Ethernet-based protocols Easy to mount on DIN rail or on walls Headless operation without keyboard and monitor Supplied without keyboard, mouse and monitor Technical Data
Dimensions (W x H x D): 262 x 134 x 47 mm Housing Dimensions incl. top-hat rail terminals: 262 x 134 x 50 mm incl. top-hat rail terminals Weight: 2 kg Power supply: external 24 V=; 19.2 ... 28.8 V= electrically isolated Protection class: IP20 Video output: DVI-DRead more
Compact, reliable, flexible. The Lighting Control Engine mx (LCEmx) has no moving parts such as fans or hard disks and can be mounted on DIN rails, on walls or in racks. Nevertheless, it has all the connections, functions and performance expected for demanding lighting projects. Equipped with high-quality components and developed for industrial use, it is the perfect server for small to medium-sized lighting installations.Engines for DMX output such as Butler or Butler XT are connected via e:net, and other network protocols such as KiNet or Art-Net are also supported. Special features such as an externally accessible CompactFlash card slot, operation without a monitor and keyboard, the SATA2 solid state drive or the wide range of mounting options make the LCEmx an exceptional system as the heart of a lighting control solution.
At a Glance
Pre-installed e:cue Lighting Application Suite with internal enterprise dongle High-quality components for reliable operation Certified for industrial use Fanless operation, no moving parts thanks to SSD drive Up to 8 GB CompactFlash card in card slot USB, RS-232 and DVI interfaces 2 x e:net/Ethernet (RJ45) Supports a wide range of Ethernet-based protocols Easy to mount on DIN rail or on walls Headless operation without keyboard and monitor Supplied without keyboard, mouse and monitor Technical Data
Dimensions (W x H x D): 262 x 134 x 47 mm Housing Dimensions incl. top-hat rail terminals: 262 x 134 x 50 mm incl. top-hat rail terminals Weight: 2 kg Power supply: external 24 V=; 19.2 ... 28.8 V= electrically isolated Protection class: IP20 Video output: DVI-DRead more
At a Glance
Pre-installed e:cue Lighting Application Suite with internal enterprise dongle High-quality components for reliable operation Certified for industrial use Fanless operation, no moving parts thanks to SSD drive Up to 8 GB CompactFlash card in card slot USB, RS-232 and DVI interfaces 2 x e:net/Ethernet (RJ45) Supports a wide range of Ethernet-based protocols Easy to mount on DIN rail or on walls Headless operation without keyboard and monitor Supplied without keyboard, mouse and monitor Technical Data
Dimensions (W x H x D): 262 x 134 x 47 mm Housing Dimensions incl. top-hat rail terminals: 262 x 134 x 50 mm incl. top-hat rail terminals Weight: 2 kg Power supply: external 24 V=; 19.2 ... 28.8 V= electrically isolated Protection class: IP20 Video output: DVI-DRead more
Specifications
| Type | Controllers & Processors |
| Brand | E:CUE |
